QUADRO 50
- For medium loads
- Aluminium elements with steel arm profiles
- Robust, modular and proven
Product description
QUADRO 50 gets its name from the 50 mm square steel profiles which form the basis of the system. Connection joints and couplings are made of high load spheroidal graphite which provides a higher than average bearing strength. The overall static equilibrium of the system is extremely high due to its use of steel profiles.
QUADRO can be assembled quickly and easily at the point of use, thanks to its sophisticated technology. The articulated parts are equipped with a swivel limiter. A control lamp adapter and a QUADRO 50/taraPLUS elbow for connection to the taraPLUS system complete the range. Compatible command enclosures include commandCASE aluFACE and profiPANEL.
Product overview
Wählen Sie hier die passende 'Startkomponente' für Ihren Tragarm aus.
Tragprofile erhalten Sie in vier Standardlängen ab Lager oder millimetergenau nach Ihren Anforderungen.
Wählen Sie die passende Adaption um Ihr Panel an das QUADRO-System anzuschließen.
Komplettieren Sie Ihr System mit den passenden Winkeln und Kupplungen.
N = Neigbar
| Image | Article name | Type | Article number | Length | Width | Height | Request | Details |
|---|---|---|---|---|---|---|---|---|
 | QUADRO 50 | Aufsatzgelenk | 147.005.500 | - | - | - | Details | |
 | QUADRO 50 | Wandgelenk | 147.010.000 | - | - | - | Details | |
 | QUADRO 50 | Zwischengelenk | 147.015.000 | - | - | - | Details | |
 | QUADRO 50 | Winkel | 147.020.500 | - | - | - | Details | |
 | QUADRO 50 | Standfuß | 147.030.000 | - | - | - | Details | |
 | QUADRO 50 | Aufsteckgelenk | 147.040.000 | - | - | - | Details | |
 | QUADRO 50 | taraPLUS/ Winkel | 149.021.000, | - | - | - | Details |
Technical data
| Principle | Closed system with easy access to system parts for medium and heavy loads |
| Additional info | Simple alignment of the system |
| Heavy-duty system parts made from spheroidal graphite | |
| Signal light adapter available for the elbow | |
| Transition from QUADRO 50 to taraPLUS around 48mm possible with special elbow | |
| Compatible ROLEC control enclosures: commandCASE, aluFACE, profiPANEL | |
| Material/coating | System elements: Aluminium and high-tensile spheroidal graphite |
| Powder coating RAL 7040, window grey | |
| Optional: Special colours | |
| Supportprofile: Steel, drawn | |
| Powder coating RAL 7035, light grey | |
| Optional: Special colours | |
| Bellows: PVC, RAL 7035, light grey | |
| Cable routing | Suitable for HDMI, patch cables, USB etc., not suitable for DVI plugs |
| Ingress protection | IP 54 / EN 60529 |
| Torque for cutting ring screws | 30 Nm = 3 kg/m |
Application examples
Frequently Asked Questions
Yes. ROLEC offers a range of options for customising the colour of your enclosures, HMI enclosures and support arm systems.
Depending on the application, the following options are available, amongst others:
• Powder coatings in almost all RAL colours
• 2K wet paint finishes
• Highly weather-resistant coatings
• Surface treatments such as SurTec 650
The most suitable coating depends on the environmental conditions and your design requirements.
Yes. Given the wide range of enclosure series, materials and configuration options available, we would definitely recommend a personal consultation.
Our experts will help you choose the right enclosure solution and support you every step of the way, from the initial idea to the finished product. In many countries, we also offer on-site consultations. Find your personal contact here.
Yes. We are happy to provide you with a sample of our products on request.
In addition, we can assist you with the development of prototypes and manufacture these, including machining, labelling or customised features. This allows the fit and function to be reliably tested even before series production begins.
Yes. Thanks to their modular design, ROLEC support arm systems can be extended, modified or adapted to new requirements at any time.
This makes modernisation easier and protects your investment in the long term.
Yes. ROLEC support arm systems are based on a modular design and can be customised to suit your specific application.
Possible configurations include, amongst others:
• Various tube lengths
• Wall, floor or machine mountings
• Angle and coupling elements
• Different extension arms
• Customised combinations of several support arm segments
• How can control panels be positioned ergonomically?
Thanks to the modular joint and coupling elements, control panels can be flexibly aligned and adapted to the respective workstation. This enables ergonomic operation and significantly improves user comfort. Please feel free to use our handy support arm configurator.
Yes. Many ROLEC mounting arm systems can also be combined with enclosures or control units from other manufacturers.
Depending on the application, VESA mounts or customised adapter solutions are available, for example for 48 mm diameter round tubing. We would be happy to check the compatibility of your existing components.
ROLEC’s support arm systems are perfectly matched to the company’s HMI enclosure ranges.
These include, amongst others:
• profiPANEL
• multiPANEL
• profiCASE
• commandCASE
Depending on the enclosure series, suitable mounting solutions are available for wall, floor-standing or support-arm mounting.
Yes. ROLEC cable support arm systems are designed so that cables can be easily installed and, if necessary, added to or replaced at a later date.
This makes it particularly efficient to carry out extensions or maintenance work.
The cable passages in ROLEC’s support arm systems provide ample space for numerous supply and data cables.
Depending on the system, the following cables, amongst others, can be routed safely:
- Power supply
- Ethernet
- Profinet
- USB
- HDMI
- DVI
- DisplayPort
- Fieldbus cables
The maximum load capacity depends on the selected support arm system, the boom length and the specific installation situation.
ROLEC offers solutions for lightweight control units as well as for heavy-duty HMI and industrial PC systems. Our experts will assist you in selecting the appropriate support arm configuration and will verify the permissible loads for your application.
Yes. The profiPLUS 50 and profiPLUS 70 support arm systems feature an integrated equipotential bonding system across all system components. This ensures a permanently safe electrical connection throughout the entire support arm system – without the need for additional earthing cables between the individual elements. For the protection of people and machinery.
ROLEC offers perfectly coordinated HMI enclosures and support arm systems, all from a single source.
Depending on the application, the following systems are used:
• profiPLUS 50 – designer support arms for light to medium loads
• profiPLUS 70 – designer support arms for medium to heavy loads
• taraSMART – modern support arm system with integrated cable routing
• taraPLUS – a cost-effective solution for numerous industrial applications
• QUADRO 50 – a robust support arm system for medium loads
• QUADRO 80 – a robust support arm system for heavy loads
Our support arm systems enable safe cable routing, high stability and ergonomic positioning of control units. We would be happy to assist you in selecting the right combination of enclosure and support arm.
